Specs
| Model | 72″ | 84″ | 96″ |
| Broom Width – Angled at 15° | 69.55″ | 81.14″ | 92.73″ |
| Broom Width – Angled at 30° | 62.35″ | 72.75″ | 83.14″ |
| Width (A) | 82″ | 94″ | 106″ |
| Depth (B) | 77″ | 77″ | 77″ |
| Height (C) | 47″ | 47″ | 47″ |
| Weight | 1063 lbs. | 1115 lbs. | 1182 lbs. |
| Max Flow (DO NOT EXCEED) | 25 gpm | 25 gpm | 25 gpm |
| Max Pressure (DO NOT EXCEED) | 3500 psi | 3500 psi | 3500 psi |
Features
Sweeps & Collects
Sweeps and collects all kinds of debris in factories, car parks, road construction, stockyards, shipping containers and more.
Bi-Directional Slew
Manual or hydraulic slew in both directions up to 30°
Optional Caster Wheel
Heavy-duty adjustable front caster wheel
Pricing On Angle Broom With Optional Attachments
| Size | Poly Wire Brush (Manual Pivot) | Poly Wire Brush (Hydraulic Pivot) | Manual Pivot W/ Jockey Wheel | Hydraulic Pivot W/ Jockey Wheel |
| 72″ | $8820 | $10,680 | $9270 | $11,110 |
| 84″ | $9210 | $11,050 | $9640 | $11,500 |
| 96″ | $9590 | $11,430 | $10,020 | $11,880 |
